SS304L 8-5/8" Slot 40 Water Well Screen For Sand Control In Water Wells

SS304L 8-5/8" Slot 40 Water Well Screen For Sand Control In Water Wells

Sand Control Water Well Screen

SS304L Water Well Screen

8-5/8" Water Well Screen

Plaats van herkomst:

Hengshui, Hebei, China

Merknaam:

Heng Yuan

Certificering:

ISO9000

Modelnummer:

85/8“

Contacteer ons

Verzoek om een Citaat
SS304L 8-5/8
SS304L 8-5/8 SS304L 8-5/8 SS304L 8-5/8 SS304L 8-5/8
Productdetails
Naam:
Waterputfilter
Materiaal:
Roestvrij staal 304L
Diameter:
219 mm
Lange:
5800mm
Grootte van het slot:
1.0 mm
Omslagdraad:
3.0×4.6mm
Ondersteuningsstaaf:
ø4.0mm
Nr van staaf:
48NOS
Eindverbinding:
API-STC-draad
Gewicht:
110KG/stuk
Pakket:
Plasticfolie
Gebruik:
In waterputten voor zandcontrole
Verwante Producten
Goede prijs SS304L 12-3/4 Video

SS304L 12-3/4" Slot 40 Water Well Screen For Irrigation

Krijg Beste Prijs
Goede prijs Stainless Steel 304L Rod Based Continuous Slot Wedge Wire Screen online Video

Stainless Steel 304L Rod Based Continuous Slot Wedge Wire Screen

Krijg Beste Prijs
Goede prijs SS304 Vee Wire Water Well Screen Non Clogging Long Lasting Performance online Video

SS304 Vee Wire Water Well Screen Non Clogging Long Lasting Performance

Krijg Beste Prijs
Goede prijs Goedkoop koolstofgehalte gegalvaniseerd waterputscherm Uitstekend drukbestendig Leveranciers online Video

Goedkoop koolstofgehalte gegalvaniseerd waterputscherm Uitstekend drukbestendig Leveranciers

Krijg Beste Prijs
Contacteer ons
86-318-7565918
hengyuan1@aphywire.com
86-318-7565919
Contact nu
Productomschrijving



8-5/8" Slot 40 Water Well Screen For Sand Control In Water Wells





Commonly referred to as continuous slot or wire wrap screen, continuous slot water well screen was originally developed to overcome problems associated with cable tool wells drilled in fine grained, uniform sands in the North Central United States.



These wells were typically completed in relatively shallow, thin aquifers that were very prolific in terms of water production.



Continuous wire wrap screen are very effective in wells of this type since they can be manufactured with very small slot size and yet still maintain the necessary open area to minimize frictional head loss.





Water Well Screen Regular Specifications:



Name:Continuous Slot Rod Based Water Well Screen,Oil Well Sand Screen,Water Well Screen,

Wedge wire screen,Screen tube,Wound screen,Sand control screen, Wedge wire screen pipe,

Rotary filter drum,Oil screen.
Material: Stainless steel 202,304,304L,316L,Non-magnetic Stainless steel,Low carbon galvanized etc.
Diameter: 3", 4", 6", 8", 10", 12", 14", 16", 18" etc.
Slot: From 0.1-100mm (Normal slot 0.5mm, 0.63mm, 0.75mm, 1.0mm, 1.5mm, Pls refer to below table)
Length: From 100-6000mm (Normal length is 2.9m/3m and 5.8m/6m, to fit container)
Wrap wire:2*3.5mm,2.2*3.5mm,3*4.6mm,3*5mm,3*6mm,3*6.5mm,3.2*6mm,4*7mm etc.
Support rod:ø3.0-ø6.0mm round wire, Also can be Vee-shaped wire.
Ends:Welded rings/Plain beveled ends,Male/female threaded,Flange etc.

Use:Water Well,Oil Wells,Waste Water Treatment,Water supply systems,Coal & Mine,

Food Processors & Beverage Screens,Environmental protection,Refining & Petrochemical,Architecture & Construction etc.

Sizes

(inch)

OD

(mm)

Slot

(mm)

Length

(m)

Tenslie

Strength

 Collapse Strength

Wrap wire

Vee-shaped wire(mm)

Support rod

Round wire(mm)
3-1/2 88.9 1.0 2.9 ＞22 10.2 2.0*3.5(Width*height) ø3.8MM×22
4-1/2 114.3 1.0 2.9 ＞28 11.5 2.0*3.5(Width*height) ø3.8MM×22
6-5/8 168.3 0.75 5.8 ＞40 12.8 2.0*3.5(Width*height) ø3.8MM×32
6-5/8 168.3 1.0 5.8 ＞33 12.8 2.2*3.5(Width*height) ø3.8MM×32
6-5/8 168.3 0.63 5.8 ＞83 45 3.0*6.0(Width*height) ø6.0MM×32
8-5/8 219.1 1.0 5.8 ＞34 21.9 2.2*3.5(Width*height) ø3.8MM×48
8-5/8 219.1 1.0 5.8 ＞50 38.2 3.0*4.6(Width*height) ø4.0MM×48
8-5/8 219.1 1.0 5.8 ＞60 46 3.0*6.0(Width*height) ø5.0MM×48
10-3/4 273.1 0.75 5.8 ＞50 32.9 2.2*3.5(Width*height) ø4.0MM×55
10-3/4 273.1 1.0 5.8 ＞60 39.5 3.0*4.6(Width*height) ø4.8MM×55
10-3/4 273.1 1.0 5.8 ＞100 48 3.2*6.0(Width*height) ø5.0MM×55
12-3/4 323.9 1.0 5.8 ＞120 37.2 3.0*5.0(Width*height) ø4.0MM×56
14 355.6 1.0 2.9 ＞80 37.8 3.0*5.5(Width*height) ø4.0MM×59
16 426 1.0 2.9 ＞80 37.5 3.0*5.5(Width*height) ø4.0MM×64




Special specification can be made according to your need !





Water Well Screen Use:


Water Well,

Food &Beverage Screens,

Pharmaceutical & Biological industries,

Refining & Petrochemical,

Water Treatment & Liquid / Solids Separation,

Mineral & Aggregate Processing,

Pulp & Paper Screens.





SS304L 8-5/8" Slot 40 Water Well Screen For Sand Control In Water Wells 0
